Product Specification
Model No. | PR-SD3015 ( PR-SD4020/PR-SD6025 optional ) |
Working Area | 3000*1500mm (4000*2000mm/6000*2500mm optional and can be customized) |
X Y Z Axis Stroke | 1520*3100*100mm |
Laser Power | 3000w (1000w/ 1500w / 2000w / 6000w / 12000w / 20000w optional) |
Maximum Acceleration | 0.8G |
X, Y Axis Positioning Accuracy | ±0.03mm |
X, Y Axis Repeat Positioning Accuracy | ±0.02mm |
Power Requirement | 380V 3PH 50/60HZ |
Cutting Ability | Carbon Steel: 22mm Stainless Steel: 10mm Aluminium: 8mm Brass: 6mm 3000w |
Total Weight | 2000kgs |
Main Configurations
Item | Brand | Brand Location | Specification |
Laser Source | Raycus | Wuhan, China | 3000W (1000w, 1500w, 2000w,6000w optional) |
Laser Cutting System | Cypcut bus system | Shanghai, China | 2000E |
Laser Cutting Head | Cypcut | Shanghai, China | BLT310 |
Lathe Bed | Plate welding | Jinan, China | More than 1000kgs |
Crossbeam | PRECISE CNC | Jinan, China | Integrated aviation aluminum |
Servo System | Cypcut/Inovance | Shanghai/Shenzhen, China | 400w,1100w,1100w/400w,850w,850w |
Reducer | TECHMECH | Shanghai, China | Flange type |
Guide Rail | PEK/YYH | Italy | 30mm, 20mm |
Gear and Rack | PEK/YYH | Italy | 2M |
Electrical Component | Honeywell | USA | Industrial grade |
Pneumatic Device | Inovance | Shenzhen, China | Integrated type |
Water Chiller | HANLI | Wuhan, China | 3000W |
Sheet Metal Laser Cutting Machine Features and Advantages
Standard Sheet Metal Fiber Laser Cutting Machine Video
Fiber Laser Cutting Machine Samples








Fiber Laser Cutting Machine Applications









Fiber Laser Cutting Machine Testimonials
Fiber Laser Cutting Machine FAQs
A: The working principle of a fiber laser cutting machine is based on the use of a high-powered laser beam to melt, burn, or vaporize the material being cut. Here’s a breakdown of the process:
1.Laser Generation: The machine generates a laser beam using a fiber optic laser source. The laser source typically uses a fiber laser (such as YAG or ytterbium-doped fiber) that is pumped with light from diodes. The laser beam is then transmitted through the fiber optic cable.
2.Beam Focusing: The laser beam is directed and focused onto the material using a set of mirrors and a focusing lens. The focused beam has very high energy density and is able to concentrate on a small spot on the material’s surface.
3.Material Interaction: When the laser beam hits the material, it rapidly heats up the surface, causing the material to melt, burn, or vaporize. The cutting area is typically assisted by auxiliary gases (like nitrogen, oxygen, or compressed air), which help blow away the molten material and improve the cut quality.
4.Cutting Process: As the laser beam moves across the material, the heat melts or vaporizes the material in the path of the beam. The cutting head is typically controlled by a CNC system, which precisely guides the laser beam to cut along the desired path.
5.Cooling: During the cutting process, the material around the laser-cut area cools and solidifies quickly, allowing for clean, precise cuts with minimal distortion.
Fiber laser cutting machines are favored for their high cutting precision, speed, and efficiency, particularly when cutting metals such as stainless steel, aluminum, and carbon steel. The fiber laser’s ability to focus energy tightly on the cutting area results in high-quality, narrow kerf widths, and minimal heat-affected zones (HAZ).
